719/560- MP s veličinom 560x680x56 mm Jednostruki kutni lopovi kuglični ležajevi
Pregled
Kuglični kuglični ležajevi sa standardiziranim glavnim dimenzijama odgovaraju DIN 628-1.
Dimenzionalne i geometrijske tolerancije standardiziranih ležajeva odgovaraju klasu tolerancije Pn na DIN 620-2.
Isti kodovi ležaja 719/{560- mp-p6; 719/{560- MP-p 5- ul; 719/56 0 mp.p5.u0; 719/560 AMB ležajevi su dostupni.
Jedan red 719 ..- MP serija s MP-solid mesinganom kavezom, vođena loptom; Ovaj mesingani kavez ima dobru otpornost na čvrstoću i toplinu koja može održati stabilnu strukturu ležaja velikom brzinom i prilagoditi se toplini koju je ležao na velikoj brzini. Kontaktirajući kut od 30 stupnjeva; Nije zapečaćen; Ovaj se ležaj mogao koristiti na radnim temperaturama od –30 stupnjeva do {+200 stupnja (dimenzionalna mu je prstena stabilizirana do 200 stupnjeva). Klasa tolerancije (PN). Moglo bi izdržati radijalna i jednosmjerna aksijalna opterećenja, a ne podmašeno je podmazano.
Promjer provrta {{0}} mm; Vanjski promjer -750 mm; širina -85 mm; Masa -101. 6 kg; cr =650 kn; c0r =1470 kn; ograničavajuća brzina =1180 1/min; referentna brzina 680 1/min.
Tehnički podaci
| Dimenzije i tehničke tablice | |
| Dio br. | 719/560- mp -single redak kutni kontaktni ležaj |
| Marka | Marka pedera napravljena u Njemačkoj/SDVV marki izrađena u Kini |
| Glavne dimenzije | 560x750x85 mm |
| d | 560 mm |
| D | 750 mm |
| B | 85 mm |
| min | 5 mm |
| D1 | 681 mm |
| Kontaktni kut | 30 stupnjeva |
| Da Min. | 578 mm |
| Da Max. | 732 mm |
| ra max. | 4 mm |
| CR | 650 kN |
| C0r | 1470 kN |
| M | 101,6 kg |
Novi Popis za dolazak
| Oznaka | Dimenzija (dxdxt) (mm) |
| A2031 A2126 | 7.937x31.991x10.008 |
| A2037 A2126 | 9.525x31.991x10.008 |
| A4044 A4138 | 11.112x34.988x10.998 |
| A2047 A2126 | 11.987x31.991x10.008 |
| A4049 A4138 | 12.680x34.988x10.998 |
| A4050 A4138 | 12.700x34.988x10.998 |
| 00050 00150 | 12.700x38.100x13.495 |
| A4059 A4138 | 14.987x34.988x10.998 |
| L21549 L21511 | 15.875x34.988x10.998 |
| A6062 A6157 | 15.875x39.992x12.014 |
| 03062 03162 | 15.875x41.275x14.288 |
| 11590 11520 | 15.875x42.862x14.288 |
| 17580 17520 | 15.875x42.862x16.670 |
| 05062 05185 | 15.875x47.000x14.381 |
| 09062 09195 | 15.875x49.225x19.845 |
| 09062 09194 | 15.875x49.225x23.020 |
| 21063 21212 | 15.875x53.975x22.225 |
| HM81649 HM81610 | 15.987x46.975x21.000 |
| A6067 A6157A | 16.993x39.982x12.014 |
| A6067 A6157 | 16.993x39.992x12.014 |
| 05066 05185 | 16.993x47.000x14.381 |
| A5069 A5144 | 17.455x36.525x11.112 |
| LM11749 LM11710 | 17.462x39.878x13.843 |
| 4C 6 | 17.462x44.450x12.700 |
| 05068 05175 | 17.462x44.450x15.494 |
| 05070XS 05185- s | 17.987x47.000x14.381 |
| 05070X 05185-S | 18.000x47.000x14.381 |
| 1774 1729 | 19.004x56.896x19.368 |
| 1774 1729X | 19.004x56.896x19.368 |
| A6075 A6157 | 19.050x39.992x12.014 |
| A6075 A6162 | 19.050x41.275x11.905 |
| 4A 6 | 19.050x44.450x12.700 |
| LM11949 LM11910 | 19.050x45.237x15.494 |
| 05075 05185 | 19.050x47.000x14.381 |
| 05075X 05185-S | 19.050x47.000x14.381 |
| 09067 09195 | 19.050x49.225x18.034 |
| 09074 09195 | 19.050x49.225x19.845 |
| 09078 09195 | 19.050x49.225x19.845 |
| 09067 09194 | 19.050x49.225x21.209 |
| 09067 09196 | 19.050x49.225x21.209 |
| 09074 09194 | 19.050x49.225x23.020 |
| 09074 09196 | 19.050x49.225x23.020 |
| 09078 09194 | 19.050x49.225x23.020 |
| 09078 09196 | 19.050x49.225x23.020 |
| 09074 09201 | 19.050x50.800x20.638 |
| LM11949 LM11919 | 19.050x52.800x18.034 |
| 09067 09194-S | 19.050x52.883x18.430 |
| 09074 09194-S | 19.050x52.883x20.241 |
| 21075 21212 | 19.050x53.975x22.225 |
| 21075 21213 | 19.050x53.975x22.225 |
| 21075A 21212 | 19.050x53.975x22.225 |
| 1775 1729 | 19.050x56.896x19.368 |
| 05079 05185A | 19.987x46.982x14.381 |
| 05079 05186 | 19.987x46.990x15.250 |
| 05079 05185 | 19.987x47.000x14.381 |
| 05079 05185-S | 19.987x47.000x14.381 |
| 07079X 07204 | 19.987x51.994x15.011 |
| XAA32004X YAA32004X | 20.000x42.000x15.000 |
| 07079 07204 | 20.000x51.994x15.011 |
| 1778 1729 | 20.627x56.896x19.368 |
| 12580 12520 | 20.638x49.225x19.845 |
| M12649 M12610 | 21.430x50.005x17.526 |
| LM12749 LM12710 | 21.987x45.237x15.494 |
| LM12749 LM12711 | 21.987x45.974x15.494 |
| LL52549 LL52510 | 22.225x42.070x11.176 |
| 07087 07196 | 22.225x50.005x13.495 |
| 07087X 07196 | 22.225x50.005x13.495 |
| M12648A M12610 | 22.225x50.005x17.526 |
| M12648 M12610 | 22.225x50.005x17.526 |
| 07087 07204 | 22.225x51.994x15.011 |
| 07087X 07205 | 22.225x52.000x15.011 |
| 1380 1328 | 22.225x52.388x19.368 |
| 1380 1329 | 22.225x53.975x19.368 |
| 1755 1730 | 22.225x53.975x19.368 |
| 1755 1729 | 22.225x56.896x19.368 |
| 1755 1729X | 22.225x56.896x19.368 |
| 1975 1922 | 22.225x57.150x19.845 |
| 1280 1220 | 22.225x57.150x22.225 |
| 1975 1932 | 22.225x58.738x19.050 |
| 1975 1931 | 22.225x60.325x19.845 |
| 3655 3620 | 22.225x61.912x36.512 |
| 246X 242 | 22.225x62.000x17.983 |
| 2684 2631 | 22.225x66.421x23.812 |
| LM72849 LM72810 | 22.606x47.000x15.500 |
| 07093 07196 | 23.812x50.005x13.495 |
| L44640 L44610 | 23.812x50.292x14.224 |
| 07093 07210X | 23.812x50.800x15.011 |
| 07093 07204 | 23.812x51.994x15.011 |
| 1779 1730 | 23.812x53.975x19.368 |
| 1779 1729 | 23.812x56.896x19.368 |
| 3659 3620 | 23.812x61.912x28.575 |
| 23092 23256 | 23.812x65.088x22.225 |
| 2685 2631 | 23.812x66.421x23.812 |
| JHM33449 JHM33410 | 24.000x55.000x25.000 |
| 43096 43312 | 24.384x79.375x25.400 |
| 07098 07196 | 24.981x50.005x13.495 |
| 07098 07204 | 24.981x51.994x15.011 |
| 07098 07205 | 24.981x52.000x15.011 |
| 17098 17244A | 24.981x61.981x16.002 |
| 17098 17244 | 24.981x62.000x16.002 |
| XAA32005X YAA32005X | 25.000x47.000x15.000 |
| 07097 07196 | 25.000x50.005x13.495 |
| 07097 07204 | 25.000x51.994x15.011 |
| JL44642A JL44615 | 25.000x52.000x14.220 |
| 07097 07205 | 25.000x52.000x15.011 |
| 247 244X | 25.000x61.912x21.018 |
| 07100-S 07196 | 25.400x50.005x13.495 |
| L44642 L44610 | 25.400x50.292x14.224 |
| L44643 L44610 | 25.400x50.292x14.224 |
| 07100-S 07210X | 25.400x50.800x15.011 |
| 07100- SA 07210X | 25.400x50.800x15.011 |
| L44643 L44613 | 25.400x51.986x15.011 |
| 07100-S 07205 | 25.400x52.000x15.011 |
| 07100- SA 07205 | 25.400x52.000x15.011 |
| 1780 1730 | 25.400x53.975x19.368 |
| 1780 1729 | 25.400x56.896x19.368 |
| 15578 15520 | 25.400x57.150x17.462 |
| M84548 M84510 | 25.400x57.150x19.431 |
| 1986 1922 | 25.400x57.150x19.845 |
| 1994X 1922 | 25.400x57.150x19.845 |
| 1780 1738X | 25.400x57.150x20.218 |
| 1986 1932 | 25.400x58.738x19.050 |
| M84249 M84210 | 25.400x59.530x23.368 |
| 15578 15523 | 25.400x60.325x19.842 |
| 1986 1931 | 25.400x60.325x19.845 |
| 1994X 1931 | 25.400x60.325x19.845 |
| 15100- sr 15245 | 25.400x62.000x18.161 |
| 15100 15245 | 25.400x62.000x19.050 |
| 15101 15245 | 25.400x62.000x19.050 |
| 15102 15245 | 25.400x62.000x19.050 |
| 15100 15244 | 25.400x62.000x20.638 |
| 15101 15244 | 25.400x62.000x20.638 |
| 2687 2630 | 25.400x63.100x23.812 |
| 15100 15250 | 25.400x63.500x20.638 |
| 15101 15250 | 25.400x63.500x20.638 |
| 15102 15250 | 25.400x63.500x20.638 |
| 15100-S 15250X | 25.400x63.500x20.638 |
| 15101 15250X | 25.400x63.500x20.638 |
| 23101X 23250X | 25.400x63.500x20.638 |
| 23100 23256 | 25.400x65.088x22.225 |
| 2687 2631 | 25.400x66.421x23.812 |
| 2473 2420 | 25.400x68.262x22.225 |
| 02473 02420 | 25.400x68.262x22.225 |
| M88036 M88010 | 25.400x68.262x22.225 |
| 26100 26274 | 25.400x69.723x19.050 |
| HM88630 HM88610 | 25.400x72.233x25.400 |
| HM88630 HM88610A | 25.400x72.233x25.400 |
| 41100 41286 | 25.400x72.626x24.608 |
| 3189 3120 | 25.400x72.626x30.162 |
| HM88630 HM88612 | 25.400x73.025x26.543 |
| L44645 L44613 | 25.987x51.986x15.011 |
| 15579X 15520 | 25.987x57.150x17.462 |
| 15103 15243 | 26.157x61.912x19.050 |
| 15103 15245 | 26.157x62.000x19.050 |
| 15103-S 15243 | 26.162x61.912x19.050 |
| 2682 2631 | 26.162x66.421x23.812 |
| 1987 1932 | 26.975x58.738x19.050 |
| 1987 1931 | 26.975x60.325x19.355 |
| L44649 L44610 | 26.987x50.292x14.224 |
| L44649 L44613 | 26.987x51.986x15.011 |
| 15580 15520 | 26.987x57.150x17.462 |
| M84549 M84510 | 26.987x57.150x19.431 |
| 1997X 1922 | 26.988x57.150x19.845 |
| 15580 15523 | 26.987x60.325x19.842 |
| 15106 15245 | 26.987x62.000x19.050 |
| 15106 15250X | 26.987x63.500x20.638 |
| 2688 2631 | 26.987x66.421x23.812 |
| 41106 41286 | 26.987x72.626x24.608 |
| JLM67042 LM67010 | 27.000x59.131x15.880 |
| 02473X 02419 | 27.987x66.987x20.500 |
| J15585 15520 | 28.000x57.150x17.460 |
| 1985 1930 | 28.575x56.896x19.845 |
| 15590 15520 | 28.575x57.150x17.462 |
| 1985 1922 | 28.575x57.150x19.845 |
| 1985 1932 | 28.575x58.738x19.050 |
| LM67043 LM67010 | 28.575x59.131x15.875 |
| 1985 1931 | 28.575x60.325x19.845 |
| 15112 15245 | 28.575x62.000x19.050 |
| 15113 15245 | 28.575x62.000x19.050 |
| 15112 15244 | 28.575x62.000x20.638 |
| 2689 2630 | 28.575x63.100x23.812 |
| 15112 15250 | 28.575x63.500x20.638 |
| 15113 15250 | 28.575x63.500x20.638 |
| 15112 15250X | 28.575x63.500x20.638 |
| M86647 M86610 | 28.575x64.292x21.433 |
| 24112 24261 | 28.575x66.421x19.050 |
| 2689 2631 | 28.575x66.421x23.812 |
| 2474 2420 | 28.575x68.262x22.225 |
| 02474 02420 | 28.575x68.262x22.225 |
| 26112 26274 | 28.575x69.723x19.050 |
| 2578 2523 | 28.575x69.850x23.812 |
| 2578 2523-S | 28.575x69.850x23.812 |
| 26112 26283 | 28.575x72.000x19.000 |
| 41125 41286 | 28.575x72.626x24.608 |
| 41126 41286 | 28.575x72.626x24.608 |
| 3192 3120 | 28.575x72.626x30.162 |
| 3198 3120 | 28.575x72.626x30.162 |
| 02872 02820 | 28.575x73.025x22.225 |
| 02872 02830 | 28.575x73.025x22.225 |
| 26112 26300 | 28.575x76.200x19.000 |
| 3198 3129 | 28.575x76.200x30.162 |
| 43112 43312 | 28.575x79.375x25.400 |
| L45449 L45410 | 29.000x50.29x14.224 |
| 2690 2631 | 29.367x66.421x23.812 |
| 2691 2631 | 29.367x66.421x23.812 |
| 17118 17244A | 29.987x61.981x16.002 |
| 17118 17244 | 29.987x62.000x16.002 |
| 15115 15245 | 29.987x62.000x18.161 |
| 15117 15245 | 29.987x62.000x19.050 |
| 15117 15244 | 29.987x62.000x20.638 |
| 15117 15244X | 29.987x62.000x20.638 |
| 15117 15250 | 29.987x63.500x20.638 |
| 02474A 02420A | 29.987x68.262x21.000 |
| 14118AS 14276 | 29.987x69.012x19.845 |
| 26118 26283 | 29.987x72.000x19.000 |
| 26118 26300 | 29.987x76.200x19.000 |
| 43117 43300 | 29.987x76.200x24.608 |
| 17118-S 17244 | 30.000x62.000x16.002 |
| 14117A 14274A | 30.000x68.956x19.845 |
| 14118 14274 | 30.000x69.012x19.845 |
| 14118 14276 | 30.000x69.012x19.845 |
| 14117A 14276 | 30.000x69.012x19.845 |
| 14118A 14274 | 30.000x69.012x19.845 |
| 2586 2523 | 30.000x69.850x23.812 |
| 2560X 2523 | 30.000x69.850x23.812 |
| 2560X 2523-S | 30.000x69.850x23.812 |
| 26118-S 26283-S | 30.000x72.000x19.000 |
| 2560X 2526X | 30.000x72.000x23.812 |
| JHM88540 JHM88513 | 30.000x72.000x29.370 |
| 2586 2525 | 30.000x72.022x23.812 |
| 3190 3126 | 30.000x72.034x30.162 |
| 14118 14283 | 30.000x72.085x22.385 |
| 14117A 14283 | 30.000x72.085x22.385 |
| 15116 15245 | 30.112x62.000x19.050 |
| 15116 15250 | 30.112x63.500x20.638 |
| 08118 08231 | 30.162x58.738x14.684 |
| 08118 08237 | 30.162x58.788x14.684 |
| 17119 17244 | 30.162x62.000x16.002 |
| M86649 M86610 | 30.162x64.292x21.433 |
| M86649P M86610P | 30.162x64.292x21.433 |
| 24118 24261 | 30.162x66.421x19.050 |
| 2558 2530 | 30.162x66.421x25.400 |
| 2558 2523 | 30.162x69.850x23.812 |
| 2558 2523-S | 30.162x69.850x23.812 |
| 3187 3120 | 30.162x72.626x30.162 |
| 3191 3120 | 30.162x72.626x30.162 |
| 28118 28300 | 30.162x76.200x20.638 |
| 43118 43300 | 30.162x76.200x24.608 |
| 43118 43312 | 30.162x79.375x25.400 |
| 28118 28315 | 30.162x80.000x21.006 |
| 15120A 15245 | 30.175x62.000x19.050 |
| 15118 15244 | 30.213x62.000x20.638 |
| 15120 15244 | 30.213x62.000x20.638 |
| 15118 15250 | 30.213x63.500x20.638 |
| 15119 15249 | 30.213x63.500x20.638 |
| 15119 15250 | 30.213x63.500x20.638 |
| 15120 15250 | 30.213x63.500x20.638 |
| 15118 15250X | 30.213x63.500x20.638 |
| 2561X 2520 | 30.213x66.421x25.400 |
| 2561X 2523 | 30.213x69.850x23.812 |
| 2561X 2523 -S | 30.213x69.850x23.812 |
| 14116 14276 | 30.226x69.012x19.845 |
| M86648A M86610 | 30.955x64.292x21.433 |
| 1674 1620 | 31.623x66.675x20.638 |
| 08125 08231 | 31.750x58.738x14.684 |
| LM67045 LM67010 | 31.750x59.131x15.875 |
| LM67047 LM67010 | 31.750x59.131x15.875 |
| LM67048 LM67010 | 31.750x59.131x15.875 |
| LM67049A LM67010 | 31.750x59.131x15.875 |
| LM67045 LM67014 | 31.750x61.986x15.875 |
| LM67048 LM67014 | 31.750x61.986x15.875 |
| LM67049A LM67014 | 31.750x61.986x15.875 |
| 15123 15245 | 31.750x62.000x18.161 |
| 15125 15245 | 31.750x62.000x19.050 |
| 15126 15245 | 31.750x62.000x19.050 |
| 15125 15244 | 31.750x62.000x20.638 |
| 15126 15244 | 31.750x62.000x20.638 |
| 15123 15250 | 31.750x63.500x19.748 |
| 15125 15250 | 31.750x63.500x20.638 |
| 15126 15250 | 31.750x63.500x20.638 |
| 15126 15250X | 31.750x63.500x20.638 |
| 2580 2520 | 31.750x66.421x25.400 |
| 2580 2530 | 31.750x66.421x25.400 |
| 2580 2520A | 31.750x66.421x25.400 |
| 2580A 2520A | 31.750x66.421x25.400 |
| 02476 02420A | 31.750x68.262x21.000 |
| 2475 2420 | 31.750x68.262x22.225 |
| 02475 02420 | 31.750x68.262x22.225 |
| 02476 02420 | 31.750x68.262x22.225 |
| 16579 16522 | 31.750x68.262x22.225 |
| M88046 M88010 | 31.750x68.262x22.225 |
| 23491 23420 | 31.750x68.262x26.988 |
| 14124 14274 | 31.750x69.012x19.845 |
| 14124 14276 | 31.750x69.012x19.845 |
| 14125A 14274 | 31.750x69.012x19.845 |
| 14125A 14276 | 31.750x69.012x19.845 |
| 14124 14277 | 31.750x69.012x22.385 |
| 2580 2523 | 31.750x69.850x23.812 |
| 2582 2523 | 31.750x69.850x23.812 |
| 2580 2523 -S | 31.750x69.850x23.812 |
| 14124 14282 | 31.750x71.996x19.002 |
| 2582 2525 | 31.750x72.022x23.812 |
| HM88644 HM88610 | 31.750x72.233x25.400 |
Popularni tagovi: 719/{560- MP - Jednostruki kutni kuglični ležaj, dobavljači, agencija, cijena, na prodaju, Trendovi provjere linearnog ležaja, metrički potisni ležajevi, Linearni ležajevi dugog udara, Koletni ležajevi konkurentne cijene, Precizni ležaj s visokim opterećenjem, Kuglični ležajevi za proizvodnju
